良い価格 オンライン

商品の詳細

家へ > 製品 >
アドレス可能な消防警報システム
>
Addressable Fire Detection And Alarm System CA100 Addressable Fire Alarm System for Small Buildings with 254 Control Points and 1 Loop Capacity and CA100 Panel Fire Safety Alarm System
全カテゴリー

従来の火災警報システム

アドレス可能な消防警報システム

ガス消しシステム

ビーム探知器

火災警報 炎検出器

4 ワイヤー 煙探知器

家庭用ガス検出器

独立系煙探知器
連絡 ください
Ms. Claire
Claire.tian@xinheantech.com
+8615986702194
今連絡してください
Addressable Fire Detection And Alarm System CA100 Addressable Fire Alarm System for Small Buildings with 254 Control Points and 1 Loop Capacity and CA100 Panel Fire Safety Alarm System
  • 名前
  • 名前
  • 名前
  • 名前

Addressable Fire Detection And Alarm System CA100 Addressable Fire Alarm System for Small Buildings with 254 Control Points and 1 Loop Capacity and CA100 Panel Fire Safety Alarm System

ブランド名: XHA
モデル番号: CA100
Moq: 1PCS
パッケージの詳細: 320mm*240mm*80mm
支払条件: T/T,Western Union
詳細情報
製品説明
詳細情報
Place of Origin:
China
証明:
CE
文書:
製品説明書 PDF
Installation:
Wall Mounted
Capacity:
254points
Trademark:
XHA
Supply Ability:
1000/Month
Types of Smoke Detectors:
Photoelectric Smoke Style
Customization:
Available | Customized Request
Name:
Addressable Fire Alarm Control Panel
Type:
Smoke Detectors
Wire Type:
Non-Polarity 2-Wired
Supply Ability:
1000PCS/Month
製品説明

Addressable Fire Alarm Control Panel For Smoke Alarm System



Addressable Fire Detection And Alarm System CA100 Addressable Fire Alarm System for Small Buildings with 254 Control Points and 1 Loop Capacity and CA100 Panel Fire Safety Alarm System 0

Introduction

The CA100 is an addressable fire alarm control panel with 1 loop of 254 capacity control points. It's suitable for small size fire alarm system such as warehouse, factory, housing, KTV or hotel etc.


Parameters

Product name Addressable fire alarm control panel Capacity 254 control points
LCD display 192*64 Main power supply AC220V± 15%, 50HZ.
Battery power supply DC 24V (1 sealed batteries: 1*12V*2.3Ah) Loop Bus wired Non-polarity 2 wired.
Contacts capacity 1A/24VDC Operating Environment Temperature -10°C~+50°C
 Humidity ≤95%.
Dimensions 320mm×240mm×80mm. Certification  CE


Main Functions

1. System self-test function. The system will test indicator light, LCD screen, sounder etc.
2. Inquiry function. Check model type zone number, device definition etc.
3. Event record. Record the fire alarm information and other operation record.
4. Data sampling.  Data analysis.
5. Setting function. Set the password, time, printer information.
6. Install and programming. Address coding, Login, Logical programming
7. Feedback function. Give real-time feedback information after starting the equipment.
8. Faulty alarm function. Automatically check the working status of main power supply, battery power supply, detectors , modules and report the detail fault information.

Addressable Fire Detection And Alarm System CA100 Addressable Fire Alarm System for Small Buildings with 254 Control Points and 1 Loop Capacity and CA100 Panel Fire Safety Alarm System 1
Product range

Conventional Fire Alarm System
Addressable fire alarm system
Gas Extinguishing control system
Beam Detector
4 wire smoke detectors with relay output.
2 wire Conventional smoke and heat detectors
Explosion-proof flame detector for fire alarm system
Standalone smoke detectors and combustable gas detector



Service

1. OEM &ODM service.
2. Provide technical support and after-sale service.
3. 1 year warranty.
4. Normally 15 working days lead time.
5. Welcome sample order.



タグ:
